Flexible electrical insulation sleeving and cable harnessing . High and low temperature hose for industrial machinery and equipment (low pressure) . Medical and laboratory tubing .
Back to list >>
Application:
>Flexible electrical insulation sleeving and cable harnessing.
>Tubing for household and commercial appliances, beverage and vending machines.
>High and low temperature hose for industrial machinery and equipment (low pressure).
>Medical and laboratory tubing
Test Item | Value |
Density 25℃ | 1.2 |
Rigidity JIS-A | 70 |
Tensile strength | 6.9Mpa(70Kgf/cm) |
Elongation at break | 400% |
Tensile strength at break JIS-A | 25Kgf/Cm |
Volume resistance | 2*1214 Ω.cm |
Breakdown Voltage (1mm) | 25KV |
Dielectric constant (*)50Hz | 3.2 |
Operating temperature range | -50℃-+200℃ |
Shrinking Ratio | about 50% |
Shrinking temperature | 90℃ above |
RoHs Compliant | Pass (SGS report) |
Low Smoking IEC 60754 | Pass |
Flammability Rating | Flame-Retardant(HSST-F Type) |
Radiation resistance - 106MGy | Pass |
Chemical resistance | Not strong acid or alkali resistance |
Fluid Resistance | Splash Protection of Aviation Fuel, Brake Fluid, Hydraulic Fluid, Lubricating Oil, Water |
Aging 200oC- 4hours, 180oC-168hours. | Pass |
Size (mm) | Before Shrinking | After Shrinking
| ||
MIN I.D.(mm) | Thickness(mm) | MAX I.D.(mm) | Thickness(mm) | |
φ1.0 | 1.0 | 0.5±0.1 | 0.6 | 0.7±0.1 |
φ1.5 | 1.5 | 0.5±0.1 | 0.8 | 0.7±0.1 |
φ2.0 | 2.0 | 0.5±0.1 | 1.2 | 0.7±0.1 |
φ2.5 | 2.5 | 0.5±0.1 | 1.5 | 0.7±0.1 |
φ3.0 | 3.0 | 0.5±0.1 | 1.8 | 0.7±0.1 |
φ3.5 | 3.5 | 0.5±0.1 | 2.0 | 0.7±0.1 |
φ4.0 | 4.0 | 0.5±0.1 | 2.5 | 0.7±0.1 |
φ4.5 | 4.5 | 0.5±0.1 | 2.8 | 0.7±0.1 |
φ5.0 | 5.0 | 0.5±0.1 | 3.0 | 0.7±0.1 |
φ6.0 | 6.0 | 0.5±0.1 | 3.8 | 0.7±0.1 |
φ7.0 | 7.0 | 0.5±0.1 | 4.0 | 0.7±0.1 |
φ8.0 | 8.0 | 0.5±0.1 | 4.8 | 0.7±0.1 |
φ9.0 | 9.0 | 0.5±0.1 | 5.0 | 0.7±0.1 |
φ10 | 10.0 | 1.0±0.1 | 6.5 | 1.7±0.1 |
φ12 | 12.0 | 1.0±0.1 | 7.0 | 1.7±0.1 |
φ15 | 15.0 | 1.0±0.1 | 9.0 | 1.7±0.1 |
φ18 | 18.0 | 1.0±0.1 | 11.0 | 1.7±0.1 |
φ20 | 20.0 | 1.0±0.1 | 13.0 | 1.7±0.1 |
φ25 | 25.0 | 1.0±0.1 | 15.0 | 1.7±0.1 |
φ30 | 30.0 | 1.0±0.1 | 18.0 | 1.7±0.1 |
φ35 | 35.0 | 1.0±0.1 | 20.0 | 1.7±0.1 |
φ40 | 38.0 | 1.0±0.1 | 25.0 | 1.7±0.1 |
φ50 | 47.0 | 1.0±0.1 | 30.0 | 1.7±0.1 |
φ60 | 57.0 | 1.5±0.1 | 38.0 | 2.5±0.1 |
φ70 | 67.0 | 1.5±0.1 | 45.0 | 2.5±0.1 |
φ80 | 77.0 | 1.5±0.1 | 48.0 | 2.5±0.1 |
φ90 | 87.0 | 1.5±0.1 | 52.0 | 2.5±0.1 |
φ100 | 97.0 | 1.5±0.1 | 57.0 | 2.5±0.1 |
φ110 | 107.0 | 1.5±0.1 | 63.0 | 2.5±0.1 |
